Friday, March 2, 2018

Forwarding event logs to a centralized logging system for compliance
src: cdn.ttgtmedia.com

In computing, syslog is a standard for message logging. It allows separation of the software that generates messages, the system that stores them, and the software that reports and analyzes them. Each message is labeled with a facility code, indicating the software type generating the message, and assigned a severity label.

Computer system designers may use syslog for system management and security auditing as well as general informational, analysis, and debugging messages. A wide variety of devices, such as printers, routers, and message receivers across many platforms use the syslog standard. This permits the consolidation of logging data from different types of systems in a central repository. Implementations of syslog exist for many operating systems.


Video Syslog



History

Syslog was developed in the 1980s by Eric Allman as part of the Sendmail project. It was readily adopted by other applications and has since become the standard logging solution on Unix-like systems. A variety of implementations also exist on other operating systems and it is commonly found in network devices, such as routers.

Syslog originally functioned as a de facto standard, without any authoritative published specification, and many implementations existed, some of which were incompatible. The Internet Engineering Task Force documented the status quo in RFC 3164. It was standardized by RFC 5424.

Various companies have attempted to claim patents for syslog implementations. This has had little effect on the use and standardization of the protocol.


Maps Syslog



Syslog message components

The information provided by the originator of a syslog message includes the facility code and the severity level. The syslog software adds information to the information header before passing the entry to the syslog receiver. Such components include an originator process ID, a timestamp, and the hostname or IP address of the device.

Facility

A facility code is used to specify the type of program that is logging the message. Messages with different facilities may be handled differently. The list of facilities available is defined by the standard:

The mapping between facility code and keyword is not uniform between operating systems and different syslog implementations.

Severity level

The list of severities is also defined by the standard:

The meaning of severity levels other than Emergency and Debug are relative to the application. For example, if the purpose of the system is to process transactions to update customer account balance information, an error in the final step should be assigned Alert level. However, an error occurring in an attempt to display the ZIP code of the customer may be assigned Error or even Warning level.

The server process which handles the message (syslogd) usually includes all lower (more severe) levels. That is, if messages are separated by individual severity, a Warning level entry will also be included in Notice, Info and Debug processing.

Message (MSG)

From RFC 3164, the message component (known as MSG) was specified as having these fields: TAG, which should be the name of the program or process that generated the message, and CONTENT which contains the details of the message.

Described in RFC 5424 (March 2009), "MSG is what was called CONTENT in RFC 3164". This RFC states:

  The TAG is now part of the header, but not as a single field.  The TAG has been split into APP-NAME, PROCID, and MSGID.  This does not totally resemble the usage of TAG, but provides the same functionality for most of the cases.

Popular syslog tools such as Rsyslog conform to this new standard.

The content field should be encoded in a UTF-8 character set and octet values in the traditional ASCII control character range should be avoided.


Introduction of syslog-ng Store Box Live Demo - YouTube
src: i.ytimg.com


Logger

The messages may be directed to various destinations, tuned by facility and severity, including console, files, remote syslog servers, or relays.

Most implementations provide a command line utility, often called logger, as well as a link library, to send messages to the log. Some implementations include reporting programs for filtering and displaying of syslog messages.


Solved: Prime Infrastructure 1.2 Syslog - Cisco Support Community
src: supportforums.cisco.com


Network protocol

When operating over a network, syslog implements a client-server application structure where the server listens on a well-known or registered port for protocol requests from clients. Historically the most common Transport Layer protocol for network logging has been User Datagram Protocol (UDP), with the server listening on port 514. As UDP lacks congestion control mechanisms, support for Transport Layer Security is required to implement and also recommended for general use on Transmission Control Protocol port 6514.


Cacti • View topic - Problem with Kiwi Syslog Server and Syslog ...
src: s16.postimage.org


Limitations

Since each process, application and operating system was written independently, there is little uniformity to the payload of the log message. For this reason, no assumption is made about its formatting or contents. A syslog message is formatted (RFC 5424 gives the Augmented Backus-Naur form (ABNF) definition), but its MSG field is not.

The network protocol is simplex communication, with no means of acknowledging the delivery to the originator.


GNS3 Talks: Syslog with Slack and Papertrail = view your GNS3 Lab ...
src: i.ytimg.com


Outlook

Various groups are working on draft standards detailing the use of syslog for more than just network and security event logging, such as its proposed application within the health care environment.

Regulations, such as the Sarbanes-Oxley Act, PCI DSS, HIPAA, and many others, are requiring organizations to implement comprehensive security measures, which often include collecting and analyzing logs from many different sources. The syslog format has proven effective in consolidating logs, as there are many open-source and proprietary tools for reporting and analysis. Converters exist from Windows Event Log as well as other log formats to syslog.

An emerging area of managed security services is the collection and analysis of syslog records for organizations. Managed Security Service Providers attempt to apply analytical techniques and artificial intelligence algorithms to detect patterns and alert customers to problems.


An in-depth look at 3 log managers | Network World
src: images.techhive.com


Internet standard documents

The Syslog protocol is defined by Request for Comments (RFC) documents published by the Internet Engineering Task Force (Internet standards). The following is a list of RFCs that define the syslog protocol:

  • RFC 3164 The BSD syslog Protocol (obsoleted by RFC 5424)
  • RFC 3195 Reliable Delivery for syslog
  • RFC 5424 The Syslog Protocol
  • RFC 5425 TLS Transport Mapping for Syslog
  • RFC 5426 Transmission of Syslog Messages over UDP
  • RFC 5427 Textual Conventions for Syslog Management
  • RFC 5848 Signed Syslog Messages
  • RFC 6012 Datagram Transport Layer Security (DTLS) Transport Mapping for Syslog
  • RFC 6587 Transmission of Syslog Messages over TCP

Installing Syslog on the Raspberry Pi using Syslog-NG - YouTube
src: i.ytimg.com


See also


Setup Centralized Log Server Using Rsyslog And LogAnalyzer On ...
src: www.unixmen.com


References


Viewing pfSense Logs Using Kiwi Syslog Server - YouTube
src: i.ytimg.com


External links

  • Internet Engineering Task Force: Datatracker: syslog Working Group (concluded)
  • SANS Institute: "The Ins and Outs of System Logging Using Syslog" (white paper)
  • National Institute of Standards and Technology: "Guide to Computer Security Log Management" (Special Publication 800-92) (white paper)
  • Network Management Software: "Understanding Syslog: Servers, Messages & Security"
  • Syslog.org
  • Paessler IT Explained - Syslog
  • NetLogger
  • MonitorWare: All about Syslog
  • Syslog Servers for Windows & Linux

Source of article : Wikipedia
